PT. SRIAYU MULTI KREASI

Showfou Pump UB-0220


DESCRIPTION PRODUCT :

Robust and compact multi-stage automatic centrifugal pump with Showfou own unique micro-processor equipped pump controller for automatic water pressure.

Designed for domestic clean water supply at single and multistory homes.

APPLICATIONS :

Very good for pumps with clean non-volatile liquids without solids or fibers in below applications as :

  • Ideal for domestic water supply
  • Pressure boosting
  • Automatic water transfer
  • Washing system
  • Small and medium size home, cottage
  • Irrigation

OPERATING LIMITS :

Cut-out flow rate : 2 LPM

Maximum ambient temperature : 40 derajad Celcius

Maximum water temperature : 40 derajad Celcius

FEATURE

Showfou UB Series SUPER electronic constant pressure pump consists of a multi-stage centrifugal pump fitted with our own unique  micro-processor equipped pump controller which keeps the pump running as long as there is a demand for water, eliminating fluctuating water pressure and annoying “cycling” situation in the presence of dripping taps etc.

Our own unique micro-processor equipped pump controller replaces the conventional pressure switch and provides strong and even pressure to eliminate cycling situation. And, it also provides advanced “loss of prime” protection which will stop the pump in “loss of prime” circumstances. Therefore, it can protect the pump from dry run damage.

The compact size UB series SUPER elevtronic constant pressure pump does not require large space for installation. And, we are using new super quiet motor with built-in thermal protector to provide non, intrusive and safe operation for consumer enjoyment.

All parts of the entire pump that are in contact with the water are manufactured from safe, corrosion resistant materials.



SPECIFICATIONS

  • Type : UB-0220
  • Power :  1/4 HP, 0,2 Kw
  • 100~200 Volt
  • Discharge : 3/4 inch 20 mm
  • Maximum Head :
    – 50 Hz : 23 M
    – 60 Hz : 22 M
  • Maximum Flow :
    – 50 Hz : 50 L/Min
    – 60 Hz : 60 L/min
  • Default starting pressure setting (ON) : 1.2 kG/cm2
  • Starting pressure setting range (ON) : 1.2~1.6 Kg/cm2
  • Weight : 10 kg
