Sewage Pump APP KENJI JSB Series


MATERIAL :

Mechanical Seal : SIC/SIC + CA/CE

Impeller : SUS 316

Shaft : SUS 316

FEATURE :

  • Vortex impeller/Non-clogging
  • Minimized abrasive wear
  • Large impeller clearane
  • Maintenance free
  • Double Mechanical Seal
  • Loss wax 316 Stainless steel

APPLICATION :

  • Medium concentration wastewater
  • Heavy duty

Technical Specification:



Type

Output Discharge F.L.A Rated

Pole

Free Passage Weight
HP kW Inch 1ø 230V 3ø 400V Cap. LPM Head (m) mm kg
JSB-05 0.5 0.37 2″ 3.4 1.4 200 9.5 2 35 13.2
JSB-10 1 0.75 2″ 6 2.2 240 14.3 2 35 18
JSB-20 2 1.5 2″ (3″) 9.8 4.2 280 18.3 2 45 34.7
JSB-30 3 2.2 2″ (3″) 5.7 360 22.1 2 45 35.8
JSB-50 5 3.7 3″ (4″) 7.5 560 23.3 2 45 56
JSB-75 7.5 5.5 3″ (4″) 11.4 600 28.8 2 45 62
