GIN PUMP TYPE YW


GIN PUMP TYPE YW Vertical Sewage and Mud Discharging Pump.

Features :

  • Easy to operate
  • Spiral in design
  • No prior water input needed for starting operation
  • Light weight and easy to be removed
  • The impeller specially designed in blockage free, semi-open. It can make pump discharging sewage and mud with a high capacity.
GIN PUMP TYPE YW

Main Application :

Effective used for sewage treatment of city construction and sewage and waste discharge for architecture projects, hotel, mine pond, dyeing and printing, paper making and textile industries.

Conditions :

The pumps can operate properly and continuously under following operation conditions :

  • working medium sand contents shall be max.25% by volume
  • Medium temperature shall be not more that 40°C and PH shall be 4-10
  • Must operated by rated electric motor.

SPECIFICATION PRODUCTS GIN PUMP TYPE YW

ModelPowerSpeedHeadFlowId Of HosePower
25-8-22.1.11.1 kW2825 r/min22 m8 m3/h25 mm38.5%
40-15-151.51.5 kW2840 r/min15 m15 m3/h40 mm15.1%
50-20-7.0.750.75 kW1390 r/min7 m10 m3/h50 mm54%
50-18-30-33 Kw2880 r/min30 m25 m3/h50 mm58%
65-25-15-2.22.2 kW2840 r/min15 m37 m3/h65 mm52%
80-40-7-2.22.2 kW1420 r/min7 m43 m3/h80 mm52%
100-80-10-44 kw1440 r/min10 m110 m3/h100 mm56 %
