Submersible Pump Tsurumi 80BP2.75S

Submersible Pump Tsurumi 80BP2.75S a basic heavy-duty, submersible sewage and wastewater pumps providing excellent foreign matter passing capability with reliable operation.
Offer a wide lineup of discharge bores ranging from 50-300 mm and motor outputs 0.4-75 kW, and come in a variety of models including high head type and single-phase BP models that can handle high volume pumping demand

Submersible Pump Tsurumi 80BP2.75S

Description :

Submersible Pump Tsurumi 80BP2.75S pump have accumulated various track record and know-how in a wide range of industrial and water treatment applications for many years. Using a channel impeller, they are designed to minimize trouble due to clogged solids and fibrous matter in pumped fluids.

Components :

  • Anti-wicking cable
  • Motor protector,
  • Dual inside mechanical seals with silicon carbide faces
  • Oil Lifter

The B-series pumps can help you keep your systems – whether for wastewater drainage, water treatment, flood control, irrigation and recreation facilities – running stably and greatly reduce your maintenance costs. Additionally, the pumps can be specially configured with discharge bores of 400 mm and greater, or as an option, adapted for dry pit applications where they can be installed indoors and outside a tank, as well as for seawater or high temperature liquids, paving the way for their use at shipyards and power plants for water intake and discharge.

Specifications :

Discharge Bore : 80 mm

Free standing : 80BP2.75S (60 Hz)

Motor output : 0.75 kW

Phase : SIngle

Starting Method : Capacitor Method

Dimension L x W x H : 296 x 195 x 383

Dry Wight : 14.5

Cable Length : 5 m
