Submersible Pump Tsurumi KTZE33-7 submersible three-phase automatic cast iron high head heavy-duty drainage pump. An innovative electrode type relay unit built into the pump automatically starts and stops the pump to eliminate dry-running. This mechanism greatly reduces power consumption and extends operating life. The cast iron body with high-chromium cast iron impeller enables it to withstands demanding conditions found in construction, aggregate and mining applications. The top discharge, side flow design assures efficient motor cooling even when it operates with its motor exposed to air. The discharge direction is selectable between vertical and inclined, which prevents folding or bending of the discharge hose.
Description :
- Designed with high-chrome impellers to withstand the most demanding conditions, including highly abrasive liquids found in construction, aggregate and mining applications.
- Versatility is increased as each pump model has the capability of being easily converted between high head and high volume performance with a simple change of impeller and wear plate.
- Dual high-pressure silicon carbide mechanical seals are isolated in the oil chamber to protect the seal faces from abrasion and corrosion.
- Tsurumi incorporates Pressure Relief Ports on the 10HP and 15HP models, exposing the mechanical seal only to the pressure developed by the sump submergence level. This has virtually eliminated the premature wear and failure of mechanical seals in higher pressure applications.
KTZE series with the added benefit of an integrally mounted electrode probe for turning the pump on and off automatically. The pump installs and handles like a standard pump yet operates automatically by simply connecting to a manual control panel.
Specifications of Submersible Pump Tsurumi KTZE33-7:
Discharge bore : 80 mm
Mode : KTZ33.7
Motor Output : 3.7
Phase : Three
Starting Method : D.O.L
Solid passage : 8.5 mm
Dry weight : 69 kg
Cable Length : 8 m
