Submersible Pump HCP 80AL25.5 widely use for dewatering for fish pond or basement and cellars, waste water, sump drainage, and flood control
FEATURE :
- A precision manufactured motor is achieved by utilizing the highest standard of quality control. All rotors adopt heat treatment methods for drive shaft assembling, and stator winding impregnated with varnish that is heat dried in an industrial oven.
- HCP’s professional assembly line, complimented with a synthesized production test, ensures the highest level of final pump quality
- Standard accessories include : cable with an epoxy resin sealed water resistant cable base, Auto-cut thermal motor protector dual mechanical seals and lip seal design
- The A-05A is an extremely practical pump, with a low temperature, oil filled motor and single seal design (CA/CE)
- Optional 1 1/2″ (40 mm) Flange for AN-21/21.5
SPECIFICATION :
- Discharge : 40 mm, 50 mm, 80 mm, 100 mm
- Limit Of Use
Liquid Temp : 0~40°C (32~104°F)
Applications : Wastewater sewage and drainage water
Submersion Depth : 30 m (100 feet) - Frequency : 50Hz
- Motor : 2P (3000 RPM) and Dry motor (A-05A : Oil motor)
- Insulation : Class B
- Protection : IP68
- Protector : Auto-Cut (A-05A 3ø none, A-05A/B/L 1ø Overheat)
- Bearing : Ball Type
- M. Seal : Double M. seal (A-05A : Single M. seal)
- Impeller : Semi-Open (A-43 : Enclosed-Channel)
PERFORMANCE SPECIFICATION Submersible Pump HCP 80AL25.5
Model : 80AL25.5
Power : 7 1/2 HP (5.5 kW)
Discharge : 3 Inch (80 mm)
Motor : 3 Phase
Start Method : Direct
Head : 28 m
Capacity : 0.6 m³/min
Capacity : 36 m³/h
Solid Passage : 20 m
Weight 3 ø : 75 kg
