Submersible Pump HCP SS05A

Submersible Pump HCP SS05A Submersible pump for water drainage, efficient for industrial needs.


  • Best structure design, dry motor, double mechanical seals, equipped with Auto-cut protector, pumps casting, outer cover adopts stainless steel material, and acid-resistant silicon carbide seals.
  • This series is suitable for all, light acid, corrosive and/or sea water applications. For strong acid purpose, please use the specified chemical pump.
Submersible Pump HCP SS05A


  • Water drainage for industries
  • Sanitary sewer, single and multi-family drainage
  • Water drainage for chemical, pharmaceutical and metal processing factory.


Precision casting with the use of an advanced, stainless investment casting method that produces the highest quality with a smooth surface finish.

Specification Of Submersible Pump HCP SS05A

Discharge : 50 mm, 80 mm, 100 mm

Limit Of Use

Liquid Temp : 0~40°C (32~104°F)

Applications : Corrosive and Food processing liquids

Submersion Depth : 30 m (100 feet)


Frequency : 50Hz

Motor : 2P (3000 RPM) and Dry motor

Insulation : Class B (0.5~3HP ) and Class F (5~10HP)

Protection : IP68

Protector : Auto-Cut

Bearing : Ball Type

M.Seal : Double M.seal

Impeller : Semi-Open


Upper Cover : SCS13(0.5HP) and SCS14(0.5~10)

Motor Frame : SUS316

Shaft End : SUS4316

Impeller : SCS14

M.seal :

* Upper : Carbon/ceramic

* Lower : Silicon/Silicon

O-ring : Viton

Casing : SCS13 (0.5HP) and SCS14 (0.5~10HP)

Cable : VCT or H07RN-F or SOW (10HP/230V : SJOW)


Pump can be customized to fit specifications


Model : SS-05A

Power : 1/2HP (0.4 kW)

Discharge : 2 Inch 150 mm)

Phase : 1 phase and 3 Phase

Start Method : Capacitor and Direct

Head : 7 m

Capacity : 0.12 m³/min

Capacity : 7.2 m³/h

Solid Passage : 10 m

Weight 1 ø : 14 kg

Weight 3 ø : 14 kg
